| Type code | KMPYE |
|---|---|
| Conforms to standard | EN 61076-2-101 |
| Additional functions | Product-specific pin allocation |
| Cable designation | With accessories |
| Contact durability | 500 |
| Electrical connection 1, function | Field device end |
| Electrical connection 1, design | Round |
| Electrical connection 1, connection type | Socket |
| Electrical connection 1, cable outlet | Straight |
| Electrical connection 1, connection technology | M12x1 A-coded as per EN 61076-2-101 |
| Electrical connection 1, number of pins/wires | 4 |
| Electrical connection 1, occupied pins/wires | 4 |
| Electrical connection 1, type of mounting | Screw-type lock with AF 18 and longitudinal knurl |
| Electrical connection for input 1, connection pattern | 00995385 |
| Electrical connection 2, function | Control side |
| Electrical connection 2, design | Round |
| Electrical connection 2, connection type | Plug |
| Electrical connection 2, cable outlet | Straight |
| Electrical connection 2, connection technology | M9x0.5 |
| Electrical connection 2, number of pins/wires | 7 |
| Electrical connection 2, occupied pins/wires | 6 |
| Electrical connection 2, type of mounting | Screw-type lock |
| Electrical connection 2, connection pattern | 00995748 |
| DC operating voltage range | 0 V … 50 V |
| Current rating at 40°C | 1 A |
| Surge resistance | 2 kV |
| Cable length | 0.3 m |
| Cable characteristic | Suitable for energy chains |
| Connector cable test conditions | Test conditions on request |
| Bending radius, flexible cable installation | ≥ 75 mm |
| Cable diameter | 5.6 mm |
| Cable design | Shielded8 x 0.24 mm² |
| Nominal conductor cross section | 0.24 mm² |
| Weight | 2.643563 lbs |
|---|---|
| Dimensions | 8.661417 × 4.724409 × 2.755906 in |
