electrical interface CPX-CTEL-4-M12-5POL Dimensions W x L x H=(* (including interlinking block), * 50 mm x 107 mm x 55 mm), Number of device interfaces=4, Diagnosis=(* – Communication error, * – Module short circuit, * – Module-orientated diagnostics, * – Undervoltage), Parameters configuring=(* – Diagnostic behaviour, * Failsafe per channel, * Forces per channel, * Idle mode per channel, * – Module parameters, * – Tool change mode), Additional functions=- Tool change mode
| Weight | 0.31967 lbs |
|---|---|
| Dimensions | 6.299213 × 5.905512 × 2.362205 in |
| Dimensions W x L x HÂ | (including interlinking block)50 mm x 107 mm x 55 mm |
| Number of device interfaces | 4 |
| Diagnosis | – Communication error- Module short circuit- Module-orientated diagnostics- Undervoltage |
| Parameters configuring | – Diagnostic behaviourFailsafe per channelForces per channelIdle mode per channel- Module parameters- Tool change mode |
| Additional functions | – Tool change mode |
| Control elements | DIL switches |
| LED displays | – I-Port status / diagnostics- Module status- Load supply status- System supply status |
| Internal cycle time | 1 ms per 1 byte of user data |
| Operating voltage range DCÂ | 18 … 30 V |
| Intrinsic current consumption at operating voltage | Typ. 65 mA |
| Max. power supply per channel | 4 x 1,6 A |
| Max. resultant current of outputs per channel | 4 x 1,6 A |
| Nominal operating voltage DCÂ | 24 V |
