| Stroke | 25 mm |
|---|---|
| Piston diameter | 100 mm |
| Type code | ADVUL |
| Cushioning | Elastic cushioning rings/pads at both ends |
| Mounting position | Any |
| Design | PistonPiston rod |
| Position sensing | For proximity sensor |
| Symbol | 991737 |
| Variants | Piston rod at one end |
| Protection against torsion/guide | Guide rod with yoke |
| Operating pressure | 1 bar … 10 bar |
| Mode of operation | Double-acting |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| Ambient temperature | -20 °C … 80 °C |
| Impact energy in the end positions | 1 J |
| Theoretical force at 6 bar, retracting | 4418 N |
| Theoretical force at 6 bar, advancing | 4712 N |
| Type of mounting | With accessoriesWith through-holeOptionally: |
| Pneumatic connection | G1/4 |
| Flange screws material | Steel, galvanized |
| Cover material | Wrought aluminum alloy |
| Piston rod material | High-alloy steel |
| Material of cylinder barrel | Wrought aluminum alloy |
ADVUL
ADVUL-100-25-P-A
$1,289.69
Double-acting cylinder with torsion-resistant piston rod by means of guide rod and yoke plate. A wide range of mounting options.
| Weight | 8.348906 lbs |
|---|---|
| Dimensions | 5.472441 × 4.76378 × 5.472441 in |
| Piston diameter | 100 mm |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 4712 N |
| Stroke | 25 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
| Position detection | Via proximity switch |
