| Size | 3540 |
|---|---|
| Adjustment range of swivel angle | 57 deg … 200 deg |
| Type code | DADL |
| Design | PistonPiston rod |
| Position sensing | For proximity sensor |
| Operating pressure | 5 bar … 8 bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| Ambient temperature | -10 °C … 60 °C |
| Product weight | 900 g |
| Type of mounting | Via through-hole and centering sleeve |
| Pneumatic connection | M5 |
| Note on materials | RoHS-compliant |
| Seals material | TPE-U(PU)NBR |
| Housing material | Hard-anodizedAluminum |
| Housing cover material | AluminumAnodized |
| Material of bearing | Polymer |
| Disc material | AnodizedAluminum |
| Material of screws | SteelGalvanized |
| Mode of operation | Single-actingPulling |
| Weight | 2.142893 lbs |
|---|---|
| Dimensions | 4.724409 × 4.724409 × 3.740157 in |
