| Type code | WA |
|---|---|
| Actuation type | Mechanical |
| Mounting position | Vertical +/- 5° |
| Manual override | Non-detenting |
| Condensate drain | Fully automatic |
| Design | Fully automatic external mechanics |
| Measured variable | Fill level |
| Valve function | 2/2, open, monostable |
| Operating pressure | 1.5 bar … 14 bar |
| Operating medium | Water |
| Storage temperature | -20 °C … 60 °C |
| Temperature of medium | 0 °C … 50 °C |
| Ambient temperature | 0 °C … 50 °C |
| Product weight | 92 g |
| Type of mounting | Line installation |
| Condensate drain connection | PK-4 |
| Pneumatic connection | M9 |
| Note on materials | Contains paint-wetting impairment substances |
| Housing material | Wrought aluminum alloy |
| Weight | 0.248514 lbs |
|---|---|
| Dimensions | 6.220472 × 2.165354 × 1.771654 in |
| Actuation type | Mechanical |
| Mounting position | Vertical +/- 5° |
| Manual override | Non-detenting |
| Condensate drain | Fully automatic |
| Structural design | Fully automatic external mechanics |
| Measured variable | Fill level |
| Valve Function | 2/2, monostable, open |
| Operating pressure | 1.5 bar … 14 bar |
| Operating medium | Water |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20 °C … 60 °C |
| Temperature of medium | 0 °C … 50 °C |
| Ambient temperature | 0 °C … 50 °C |
| Product weight | 92 g |
| Type of mounting | Line installation |
| Condensate drain connection | PK-4 |
| Pneumatic connection | M9 |
| Housing material | Wrought aluminum alloy |
