solenoid valve JMDH-5/2-3/4-D-4 Without pilot valve or manual override, without plug socket Valve function=5/2 bistable, Type of actuation=electrical, Width=76 mm, Standard nominal flow rate=6000 l/min, Operating pressure=2 – 16 bar
| Valve function | 5/2 bistable |
|---|---|
| Type of actuation | electrical |
| Width | 76 mm |
| Standard nominal flow rate | 6,000 l/min |
| Operating pressure | 2 … 16 bar |
| Design structure | Piston slide |
| Protection class | IP65 |
| Nominal size | 18 mm |
| Grid dimension | 82 mm |
| Exhaust-air function | throttleable |
| Sealing principle | soft |
| Assembly position | Any |
| Conforms to standard | ISO 5599-1 |
