| Stroke | 30 mm |
|---|---|
| Piston diameter | 25 mm |
| Drive unit operating mode | Yoke |
| Cushioning | Pneumatic cushioning, adjustable at both ends |
| Mounting position | Any |
| Guide | Sliding guide |
| Structural design | Guide |
| Position sensing | For proximity sensor |
| Operating pressure | 0.15 MPa … 1 MPa |
| Operating pressure | 1.5 bar … 10 bar |
| Mode of operation | Double-acting |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| LABS conformity | VDMA24364-B1/B2-L |
| Ambient temperature | -20 °C … 80 °C |
| Impact energy in the end positions | 0.3 J |
| Theoretical force at 6 bar, retracting | 247 N |
| Theoretical force at 6 bar, advancing | 295 N |
| Alternative connections | See product drawing |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Cover material | Wrought aluminum alloy |
| Seals material | NBR |
| Housing material | Wrought aluminum alloy |
| Piston rod material | High-alloy stainless steel |
| Weight | 3.421574 lbs |
|---|---|
| Dimensions | 4.92126 × 3.937008 × 1.771654 in |
| Piston diameter | 25 mm |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 295 N |
| Stroke | 30 mm |
| Cushioning | adjustable at both ends, Pneumatic cushioning |
| Position detection | Via proximity switch |
