| Structural design | Sub base valve |
|---|---|
| Actuation type | Pneumatic |
| Sealing principle | Soft |
| Mounting position | Any |
| Type of mounting | With accessories |
| Valve function | Proportional 3/3-way valve |
| Mode of operation | Double-acting |
| Operating pressure | 0.14MPa |
| Operating pressure | 1.4bar |
| Operating pressure | 20.3psi |
| Reset method | Mechanical spring |
| Pneumatic connection | Sub-base design, airing |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:7:-] |
| Information on operating and pilot media | Operation with oil lubrication not possible |
| Temperature of medium | -40°C |
| Ambient temperature | -40°C |
| Standard nominal flow rate | 1240l/min |
| C value | 5.58l/sbar |
| b-value | 0.214 |
| Note on materials | RoHS-compliant |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Housing material | Smooth-anodized wrought aluminum alloy (20 µm) |
| Cover material | Smooth-anodized wrought aluminum alloy (20 µm) |
| Seals material | EPDM |
| Material of screws | High-alloy stainless steel |
| Material of spring | Spring steel |
| Product weight | 1560g |
| Weight | 3.474485 lbs |
|---|---|
| Dimensions | 3.937008 × 3.543307 × 3.149606 in |
