| Size | M8 |
|---|---|
| Stroke | 1.3mm |
| Cushioning | Elastic cushioning rings/pads at both ends, without fixed metal stop |
| Mounting position | Any |
| Position sensing | None |
| Variants | Metals with copper, zinc or nickel as main constituent are excluded from use. Exceptions are nickel in steel, chemically nickel-plated surfaces, printed circuit boards, cables, electrical plug connectors and coils. |
| Max. impact velocity | 0.8m/s |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -10°C |
| Cushioning length | 1.3mm |
| Max. tightening torque | 2Nm |
| Max. energy absorption per stroke | 0.12J |
| Product weight | 23g |
| Type of mounting | With threaded sleeve |
| Note on materials | RoHS-compliant |
| Seals material | NBR |
| Housing material | High-alloy steel |
| Weight | 0.049075 lbs |
|---|---|
| Dimensions | 4.330709 × 3.149606 × 0.590551 in |
