| Width | 13 mm |
|---|---|
| Type code | VABS |
| Mounting position | Any |
| Design | Connection direction at side |
| Max. no. of valve positions | Versions according to customer specifications possible |
| Operating pressure | -1 bar … 7 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [6:4:1] |
| Information on operating and pilot media | Maximum particle size 5 µm |
| Ambient temperature | 5 °C … 50 °C |
| Product weight | 3 g |
| Type of mounting | With through-hole |
| Pneumatic connection 2 | For tubing I.D. 4 mm |
| Note on materials | Contains paint-wetting impairment substancesRoHS-compliant |
| Manifold rail material | PBT |
| Weight | 0.011244 lbs |
|---|---|
| Dimensions | 3.937008 × 1.968504 × 0.11811 in |
