| Stroke | 25mm |
|---|---|
| Piston diameter | 50 mm |
| Cushioning | Elastic cushioning rings/pads at both ends |
| Mounting position | Any |
| Mode of operation | Pushing |
| Piston rod end | External thread |
| Structural design | Piston |
| Position sensing | For proximity sensor |
| Symbol | 00991729 |
| Variants | Piston rod at one end |
| Operating pressure | 0.04MPa |
| Operating pressure | 0.4bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Corrosion resistance class (CRC) | 1 – Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | 0°C |
| Impact energy in the end positions | 1J |
| Theoretical force at 6 bar, retracting | 71.5N |
| Theoretical force at 6 bar, advancing | 1106N |
| Moving mass at 0Â mm stroke | 104g |
| Additional moving mass per 10Â mm stroke | 16g |
| Basic weight with 0Â mm stroke | 324g |
| Additional weight per 10Â mm stroke | 63g |
| Type of mounting | Optionally: |
| Pneumatic connection | G1/8 |
| Note on materials | RoHS-compliant |
| Cover material | Wrought aluminum alloy, anodized |
| Material of dynamic seals | TPE-U(PU) |
| Housing material | Wrought aluminum alloy, anodized |
| Piston rod material | High-alloy stainless steel |
| Weight | 1.191114 lbs |
|---|---|
| Dimensions | 6.299213 × 5.511811 × 2.362205 in |
| Mode of operation | Pushing |
| Piston diameter | 50 mm |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 1106 N |
| Stroke | 25 mm |
| Cushioning | Elastic cushioning rings/plates at both ends |
