| Type code | VFFG |
|---|---|
| Valve function | Flow control function |
| Type of mounting | Tapped |
| Operating pressure | -0.9 bar … 10 bar |
| Ambient temperature | -5 °C … 60 °C |
| Size | For 5.8 mm diameter |
| Nominal width | 0.7 mm … 1.8 mm |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:4:4] |
| Information on operating and pilot media | Operation with oil lubrication possible (required for further use) |
| Storage temperature | -20 °C … 40 °C |
| Note on materials | RoHS-compliant |
| Weight | 0.077581 lbs |
|---|---|
| Dimensions | 0.787402 × 0.393701 × 0.393701 in |
