| Type code | NEBV |
|---|---|
| Electrical connection 1, information on cable outlet | Can be rotated through 180° |
| Cable designation | Without label holder |
| Contact durability | 50 |
| Product weight | 235 g |
| Electrical connection 1, function | Field device end |
| Electrical connection 1, design | Rectangular |
| Electrical connection 1, connection type | Socket, narrow |
| Electrical connection 1, cable outlet | Angled |
| Electrical connection 1, connection technology | Connection diagram type C as per EN 175301-803 |
| Electrical connection 1, number of pins/wires | 4 |
| Electrical connection 1, occupied pins/wires | 4 |
| Electrical connection 1, type of mounting | On air solenoid valve with M2.5 central screw |
| Electrical connection for input 1, connection pattern | 995798 |
| Electrical connection 2, function | Control side |
| Electrical connection 2, connection type | Cable |
| Electrical connection 2, connection technology | Open end |
| Electrical connection 2, number of pins/wires | 3 |
| Electrical connection 2, occupied pins/wires | 3 |
| DC operating voltage range | 0 V … 230 V |
| Operating voltage range AC | 0 V … 230 V |
| Current rating at 40°C | 0.25 |
| Surge resistance | 4 kV |
| Protective earth connection | Available |
| Cable length | 5 m |
| Cable characteristic | Standard |
| Connector cable test conditions | Test conditions on request |
| Bending radius, flexible cable installation | ≥ 52 mm |
| Cable diameter | 5.2 mm |
| Cable diameter tolerance | ± 0.1 mm |
| Cable design | 3 x 0.5 mm² |
| Nominal conductor cross section | 0.5 mm² |
| Degree of protection | IP65IP67 |
| Note on degree of protection | In mounted state |
| Ambient temperature | -20 °C … 70 °C |
| Ambient temperature with flexible cable installation | -5 °C … 70 °C |
| CE marking (see declaration of conformity) | As per EU low voltage directive |
| Note on materials | RoHS-compliant |
| Contamination level | 3 |
| Corrosion resistance class (CRC) | 3 – High corrosion stress |
| Material of cable sheath | PVC |
| Color cable sheath | Gray |
| Housing material | TPE-U(PU) |
| Housing colour | Black |
| Material of screws | Stainless steel |
| Seals material | HNBR |
| Material of pin contacts | Copper alloy, tin-plated |
| Insulating sheath material | PVC |
| Weight | 0.525141 lbs |
|---|---|
| Dimensions | 9.055118 × 7.874016 × 0.787402 in |
| Electrical connection 1, connection type | narrow, Socket |
| Electrical connection 1, connector system | Plug pattern type C to EN 175301-803 |
| Electrical connection 2, connection type | Cable |
| Electrical connection 2, connector system | Open end |
| Cable length | 5 m |
