PEN-14X2-SW Plastic tubing (50 Meters)

$164.50

50 Meters
SKU: 570516
UNSPSC: 40183001
GTIN: 4052568058500

SKU: 570516 Category: Tag:
Festo

plastic tubing PEN-14X2-SW Outside diameter=14 mm, Bending radius relevant for flow rate=80 mm, Inside diameter=9,5 mm, Min. bending radius=45 mm, Temperature dependent operating pressure=-0,95 – 10 bar

Outside diameter 14 mm
Bending radius relevant for flow rate  80 mm
Inside diameter  9.5 mm
Min. bending radius  45 mm
Tubing characteristics  Suitable for energy chains in applications with high cycle rates
Tubing test conditions  Suitable for energy chains: > 5 million cycles to FN 942021
Temperature dependent operating pressure  ‘-0.95 … 10 bar
Operating medium  Compressed air in accordance with ISO8573-1:2010 [7:-:-]Water as per manufacturer’s declaration at www.festo.com
Ambient temperature  ‘-30 … 60 °C
Authorisation  TÜV
Product weight according to length  0.0773 kg/m
Pneumatic connection  For push-in connector outside diameter 14 mm
Color Black
Outside diameter

14 mm

Bending radius relevant for flow rate

80 mm

Inside diameter

9.5 mm

Min. bending radius

45 mm

Tubing characteristics

Suitable for energy chains in applications with high cycle rates

Tubing test conditions

Suitable for energy chains: > 5 million cycles to FN 942021

Temperature dependent operating pressure

-0.95 … 10 bar

Operating medium

Compressed air in accordance with ISO8573-1:2010 [7:-:-]Water as per manufacturer's declaration at http://www.festo.com

Ambient temperature

-30 … 60 °C

Authorisation

TÜV

Product weight according to length

0.0773 kg/m

Pneumatic connection

For push-in connector outside diameter 14 mm

Color

Black
