| Dimensions W x L x H | (incl. interlinking block and connection system) 50 mm x 107 mm x 70 mm |
|---|---|
| No. of inputs | 8 |
| CE marking (see declaration of conformity) | as per EU explosion protection directive (ATEX) |
| Explosion protection certification outside the EU | EPL Da (BR) EPL Da (IEC-EX) EPL Ga (BR) EPL Ga (IEC-EX) |
| Explosion prevention and protection | Zone 0 (BR) Zone 20 (BR) Zone 0 (IEC-EX) Zone 20 (IEC-EX) |
| Certificate issuing authority | DNV 15.0192 X IECEx ZLM 12.0007 X ZELM 12 ATEX 0500 X |
| ATEX category gas | II (1) G |
| ATEX category for dust | II (1) D |
| Type of ignition protection for gas | [Ex ia Ga] IIC |
| Type of (ignition) protection for dust | [Ex ia Da] IIIC |
| Explosive ambient temperature | -5°C <= Ta <= +50°C |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress (when installed) |
| Storage temperature | -20 °C … 70 °C |
| Relative air humidity | 95 % Non-condensing |
| Degree of protection | IP20 |
| Ambient temperature | -5 °C … 50 °C |
| Product weight | 100 g |
| Electrical connection | 8-pin/8-pin |
| Type of mounting | On interlinking block CPX-M-GE… |
| Note on materials | RoHS-compliant |
| Housing material | PA-reinforced |
