flow sensor SFAM-62-3000L-TG12-2SV-M12 For threaded mounting. Authorisation=(* RCM Mark, * c UL us – Recognized (OL)), CE mark (see declaration of conformity)=to EU directive for EMC, Materials note=Conforms to RoHS, Measured variable=(* Flow rate , * Consumption), Direction of flow=(* Unidirectional, * From left to right)
| Authorisation | RCM Markc UL us – Recognized (OL) |
|---|---|
| CE mark (see declaration of conformity)Â | to EU directive for EMCin accordance with EU RoHS directive |
| KC mark | KC-EMV |
| Certificate issuing department | UL E322346 |
| Materials note | Conforms to RoHS |
| Measured variable | Flow rate Consumption |
| Direction of flow | UnidirectionalFrom left to right |
| Measuring principle | Thermal |
| Flow measurement range initial value | 30 l/min |
| Flow measurement range final value | 3,000 l/min |
| Operating pressure | 0 … 16 bar |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:4:4]Nitrogen |
| Medium temperature | 0 … 50 °C |
