plastic tubing PEN-16X2,5-RT standard O.D tubing, for QS plug connectors, polyethylene (not approved for use in the food industry). Outside diameter=16 mm, Bending radius relevant for flow rate=122 mm, Inside diameter=10,8 mm, Min. bending radius=57,5 mm, Temperature dependent operating pressure=-0,95 – 10 bar
| Outside diameter | 16 mm |
|---|---|
| Bending radius relevant for flow rate | 122 mm |
| Inside diameter | 10.8 mm |
| Min. bending radius | 57.5 mm |
| Tubing characteristics | Suitable for energy chains in applications with high cycle rates |
| Tubing test conditions | Suitable for energy chains: > 5 million cycles to FN 942021 |
| Temperature dependent operating pressure | ‘-0.95 … 10 bar |
| Operating medium | Compressed air in accordance with ISO8573-1:2010 [7:-:-]Water as per manufacturer’s declaration at www.festo.com |
| Ambient temperature | ‘-30 … 60 °C |
| Authorisation | TÜV |
| Product weight according to length | 0.1029 kg/m |
| Pneumatic connection | For push-in connector outside diameter 16 mm |
| Color | Red |
