Name: LF-D-5M-MAXI-A-U
Brand: Festo
SKU: 546467
Availability: InStock

filter LF-D-5M-MAXI-A-U Without threaded connection plates with FRB threaded pin. Degree of filtration: 5 µm, with bowl guard and automatic condensate drain. Size=Maxi, Series=D, Assembly position=Vertical +/- 5°, Grade of filtration=5 µm, Condensate drain=fully automatic

Size	Maxi
Series	D
Assembly position	Vertical +/- 5°
Grade of filtration	5 µm
Condensate drain	fully automatic
Design structure	Sintered filter with centrifugal separator
Max. condensate volume	2.72 oz(l)
Bowl guard	Metal bowl guard
Operating pressure	28 … 180 Psi
Standard nominal flow rate	129.5 cfm
Operating medium	Compressed air to ISO 8573-1:2010 [7:9:-]Inert gases
Corrosion resistance classification CRC	2 – Moderate corrosion stress
Storage temperature	14 … 140 °F

Weight	2.583818 lbs
Dimensions	11.181102 × 4.80315 × 3.740157 in
Size	Maxi
Series	D
Mounting position	Vertical +/- 5°
Grade of filtration	5 µm
Condensate drain	Fully automatic
Structural design	Sinter filter with centrifugal separator
Bowl guard	Metal bowl guard
Degree of condensate separation	75 %
Symbol	00991520
Operating pressure	29 psi … 174 psi
Normal nominal flow rate (normalized to DIN 1343)	16461.86 l/min
Operating medium	Compressed air as per ISO 8573-1:2010 [7:9:-], Inert gas
Corrosion resistance class (CRC)	2 – Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Storage temperature	-10 °C … 60 °C
Air quality class at the output	Compressed air as per ISO 8573-1:2010 [6:8:4], Inert gas
Temperature of medium	5 °C … 60 °C
Ambient temperature	5 °C … 60 °C
Product weight	1329.615 g
Type of mounting	With accessories
Note on materials	RoHS-compliant
Compressed air filter material	PE
Housing material	Die-cast zinc
Material of bowl	PC
