| Working length | 15 m |
|---|---|
| Outside diameter | 6.3 mm |
| Block length | 0.67 m |
| Inside diameter | 4.7 mm |
| Winding diameter | 75 mm |
| Number of windings | 90 |
| Type code | PPS |
| Temperature-dependent operating pressure | -0.95 bar … 21.2 bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class (CRC) | 1 – Low corrosion stress |
| Ambient temperature | -30 °C … 80 °C |
| Nominal tightening torque | 11 Nm |
| Tolerance for nominal tightening torque | ± 20% |
| Product weight | 367 g |
| Pneumatic connection 1 | External thread G1/4 |
| Pneumatic connection 2 | External thread G1/4 |
| Color | Blue |
| Material of connecting thread | Brass |
| Note on materials | RoHS-compliant |
| Antikink device material | SteelGalvanized |
| Material of pneumatic tubing | PA12-P |
| Weight | 0.873031 lbs |
|---|---|
| Dimensions | 22.440945 × 3.149606 × 3.149606 in |
| Outside diameter | 6.3 mm |
| Inside diameter | 4.7 mm |
| Working length | 15 m |
| Temperature-dependent operating pressure | -0.95 bar – 21.2 bar |
| Ambient temperature | -30?C – 80?C |
