LF-D-5M-MINI

$54.51

Festo

filter
LF-D-5M-MINI
Part number: 192557

Classic

Without threaded connection plates with FRB threaded pin. Degree of filtration: 5 µm, with bowl guard and manual condensate drain.

Modern alternatives can be found by entering the first four characters of the type code in the search field.

Size  Mini
Series  D
Assembly position  Vertical +/- 5°
Grade of filtration  5 µm
Condensate drain  manual rotary
Design structure  Sintered filter with centrifugal separator
Max. condensate volume  22 cm3
Bowl guard  Metal bowl guard
Operating pressure  0 … 16 bar
Operating medium  Compressed air to ISO 8573-1:2010 [-:9:-]Inert gases
Corrosion resistance classification CRC  2 – Moderate corrosion stress
Air purity class at output  Compressed air in accordance with ISO8573-1:2010 [6:8:4]Inert gases
Medium temperature  ‘-10 … 60 °C
Size

Mini

Series

D

Assembly position

Vertical +/- 5°

Grade of filtration

5 µm

Condensate drain

manual rotary

Design structure

Sintered filter with centrifugal separator

Max. condensate volume

22 cm3

Bowl guard

Metal bowl guard

Operating pressure

0 … 16 bar

Operating medium

Compressed air to ISO 8573-1:2010 [-:9:-]Inert gases

Corrosion resistance classification CRC

2 – Moderate corrosion stress

Air purity class at output

Compressed air in accordance with ISO8573-1:2010 [6:8:4]Inert gases

Medium temperature

-10 … 60 °C
