LF-D-MINI-A

$105.55

Festo

filter
LF-D-MINI-A
Part number: 192554

Classic

Without threaded connection plates. Grade of filtration 40 µm, with bowl guard and automatic condensate drain.

Modern alternatives can be found by entering the first four characters of the type code in the search field.

Size  Mini
Series  D
Assembly position  Vertical +/- 5°
Grade of filtration  40 µm
Condensate drain  fully automatic
Design structure  Sintered filter with centrifugal separator
Max. condensate volume  22 cm3
Bowl guard  Metal bowl guard
Operating pressure  2 … 12 bar
Operating medium  Compressed air to ISO 8573-1:2010 [7:9:-]Inert gases
Corrosion resistance classification CRC  2 – Moderate corrosion stress
Storage temperature  ‘-10 … 60 °C
Air purity class at output  Compressed air in accordance with ISO8573-1:2010 [7:8:4]Inert gases
Size

Mini

Series

D

Assembly position

Vertical +/- 5°

Grade of filtration

40 µm

Condensate drain

fully automatic

Design structure

Sintered filter with centrifugal separator

Max. condensate volume

22 cm3

Bowl guard

Metal bowl guard

Operating pressure

2 … 12 bar

Operating medium

Compressed air to ISO 8573-1:2010 [7:9:-]Inert gases

Corrosion resistance classification CRC

2 – Moderate corrosion stress

Storage temperature

-10 … 60 °C

Air purity class at output

Compressed air in accordance with ISO8573-1:2010 [7:8:4]Inert gases
