| Series | D |
|---|---|
| Size | Mini |
| Type code | LFMA |
| Grade of filtration | 0.01 µm |
| Condensate drain | Manual, non-detenting |
| Symbol | 991519 |
| Operating pressure | 1 bar … 16 bar |
| Operating medium | Inert gasCompressed air as per ISO 8573-1:2010 [6:8:4] |
| Air quality class at the output | Compressed air as per ISO 8573-1:2010 [1:7:2]Inert gas |
| Max. standard flow rate for air quality class | 410 l/min |
| Min. standard flow rate for air quality class | 100 l/min |
| Filter efficiency | 0.999999 |
| Bowl guard | Metal bowl guard |
| Corrosion resistance class (CRC) | 2 – Moderate corrosion stress |
| Temperature of medium | 1.5 °C … 60 °C |
| Ambient temperature | -10 °C … 60 °C |
| Residual oil content | 0.01 mg/m³ |
| Type of mounting | Optionally:Line installationWith mounting bracket |
| Mounting position | Vertical |
| Pneumatic connection 1 | 1/4 NPT |
| Pneumatic connection 2 | 1/4 NPT |
| Housing material | Die-cast zinc |
| Compressed air filter material | Borosilicate fiber |
| Note on materials | Free of copper and PTFERoHS-compliant |
