Size | Standard |
---|---|
Nominal width | 4 mm |
Type code | NPKA |
Type of seal on screwed trunnion | Sealing ring |
Mounting position | Any |
Pack size | 10 |
Design | Push-pull principle |
Operating pressure | -0.95 bar … 10 bar |
Temperature-dependent operating pressure | -0.95 bar … 10 bar |
Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-]Water as per manufacturer’s declaration at www.festo.com |
Information on operating and pilot media | Operation with oil lubrication possible |
For use in the food industry | See supplementary material information |
Ambient temperature | -10 °C … 60 °C |
Max. tightening torque | 2 Nm |
Nominal tightening torque | 1.25 Nm |
Tolerance for nominal tightening torque | ± 20% |
Product weight | 7.5 g |
Pneumatic connection 1 | External thread G1/8 |
Pneumatic connection 2 | for pneumatic tubing outside diameter 6 mm |
Note on materials | RoHS-compliant |
Housing material | PA66-GF30 |
Material of threaded seal | PA66-GF30/TPE-U |
Sleeve material | POM |
