| Type code | VZWD |
|---|---|
| Design | Directly controlled poppet valve |
| Actuation type | Electrical |
| Sealing principle | Soft |
| Mounting position | Any |
| Type of mounting | Line installation |
| Fitting connection | NPT1/4 |
| Electrical connection | Plugas per EN 175301-803Form ARectangular design |
| Nominal width | 6 mm |
| Valve function | 2/2, closed, monostable |
| Manual override | None |
| Flow direction | Non-reversible |
| Medium | Other flow media on requestNeutral liquidsInert gasCompressed air as per ISO 8573-1:2010 [7:4:4]Mineral oilWater |
| Nominal pressure of fitting PN | 100 |
| Differential pressure | 0 bar |
| Coil characteristics | 24 V DC: 11.0 W |
| Insulation class | H |
| Permissible voltage fluctuations | +/- 10 % |
| Duty cycle | 1 |
| Reset method | Mechanical spring |
| Type of control | Direct |
| Symbol | 992979 |
| Medium pressure | 0 bar … 4 bar |
| Temperature of medium | -10 °C … 80 °C |
| Ambient temperature | -10 °C … 35 °C |
| Leak rate to EN 12266-1 | A |
| Flow rate Kv | 0.4 m³/h |
| Standard nominal flow rate | 430 l/min |
| On switching time | 20 ms |
| Switching time off | 18 ms |
| Note on materials | RoHS-compliantContains paint-wetting impairment substances |
| Housing material | Brass |
| Material number of housing | CW614N |
| Seals material | FPM |
| Product weight | 600 g |
| Degree of protection | IP65 |
| Corrosion resistance class (CRC) | 1 – Low corrosion stress |
| Weight | 1.129516 lbs |
|---|---|
| Dimensions | 4.330709 × 2.559055 × 3.543307 in |
| Design | Directly actuated poppet valve |
| Flow rate Kv | 0.4 m?/h |
| Connection Process valve | NPT1/4 |
| Type of actuation | Electric |
