| Outside diameter | 6 mm |
|---|---|
| Bending radius relevant for flow rate | 20 mm |
| Inside diameter | 2.5 mm |
| Min. bending radius | 10 mm |
| Type code | PAN-V0 |
| Temperature-dependent operating pressure | -0.95 bar … 12 bar |
| Operating medium | Mineral oilCompressed air as per ISO 8573-1:2010 [7:-:-]Water as per manufacturer’s declaration at www.festo.com |
| Material fire test | UL94 V-0 (casing) |
| Ambient temperature | -30 °C … 90 °C |
| Product weight by length | 0.0335 kg/m |
| Pneumatic connection | For plug connection outside diameter 4 mm |
| Color | Blue |
| Shore hardness | D 57 +/-3A 72 +/-4 |
| Note on materials | RoHS-compliant |
| Material of pneumatic tubing | PA12-PPVC-P |
| Weight | 0.081791 lbs |
|---|---|
| Dimensions | 18.110236 × 18.110236 × 2.559055 in |
| Outside diameter | 6 mm |
| Inside diameter | 2.5 mm |
| Temperature-dependent operating pressure | -0.95 bar – 12 bar |
| Ambient temperature | -30?C – 90?C |
