| Size | Standard |
|---|---|
| Nominal width | 4 mm |
| Type code | NPKA |
| Type of seal on screwed trunnion | Sealing ring |
| Mounting position | Any |
| Pack size | 10 |
| Design | Push-pull principle |
| Operating pressure | -0.95 bar … 10 bar |
| Temperature-dependent operating pressure | -0.95 bar … 10 bar |
| Operating medium | Compressed air as per ISO 8573-1:2010 [7:-:-]Water as per manufacturer’s declaration at www.festo.com |
| Information on operating and pilot media | Operation with oil lubrication possible |
| For use in the food industry | See supplementary material information |
| Ambient temperature | -10 °C … 60 °C |
| Max. tightening torque | 2 Nm |
| Nominal tightening torque | 1.25 Nm |
| Tolerance for nominal tightening torque | ± 20% |
| Product weight | 4.2 g |
| Pneumatic connection 1 | External thread G1/8 |
| Pneumatic connection 2 | for pneumatic tubing outside diameter 6 mm |
| Note on materials | RoHS-compliant |
| Housing material | PA66-GF30 |
| Material of threaded seal | PA66-GF30/TPE-U |
| Sleeve material | POM |
| Weight | 0.009621 lbs |
|---|---|
| Dimensions | 1.338583 × 0.511811 × 0.511811 in |
| Pneumatic connection, port 1 | Male thread G1/8 |
| Pneumatic connection, port 2 | For tubing outside diameter of 6 mm |
| Ambient temperature | -10?C – 60?C |
