filter LF-D-5M-MINI-U Without threaded connection plates with FRB threaded pin. Degree of filtration: 5 µm, with bowl guard and manual condensate drain. Size=Mini, Series=D, Assembly position=Vertical +/- 5°, Grade of filtration=5 µm, Condensate drain=manual rotary
Size | Mini |
---|---|
Series | D |
Assembly position | Vertical +/- 5° |
Grade of filtration | 5 µm |
Condensate drain | manual rotary |
Design structure | Sintered filter with centrifugal separator |
Max. condensate volume | 0.748 oz(l) |
Bowl guard | Metal bowl guard |
Operating pressure | 0 … 240 Psi |
Standard nominal flow rate | 28 cfm |
Operating medium | Compressed air to ISO 8573-1:2010 [-:9:-]Inert gases |
Corrosion resistance classification CRCÂ | 2 – Moderate corrosion stress |
Air purity class at output | Compressed air in accordance with ISO8573-1:2010 [6:8:4]Inert gases |
