HEP-1-D-MAXI

$230.20

SKU: 193260 Category: Tag: Brand:

on-off valve
HEP-1-D-MAXI
Part number: 193260

Classic

Used in conjunction with service units.

Modern alternatives can be found by entering the first four characters of the type code in the search field.

Design structure Piston slide
Type of actuation pneumatic
Sealing principle soft
Exhaust-air function not throttleable
Manual override None
Type of reset mechanical spring
Valve function 3/2 closed, monostable
Operating pressure 0 … 16 bar
Pilot pressure 3 … 16 bar
C value 27.6 l/sbar
b value 0.32
Standard nominal flow rate 6,500 l/min
Operating medium Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases
Design structure

Piston slide

Type of actuation

pneumatic

Sealing principle

soft

Exhaust-air function

not throttleable

Manual override

None

Type of reset

mechanical spring

Valve function

3/2 closed, monostable

Operating pressure

0 … 16 bar

Pilot pressure

3 … 16 bar

C value

27.6 l/sbar

b value

0.32

Standard nominal flow rate

6,500 l/min

Operating medium

Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases
