HEP-1/4-D-MIDI

$127.03

Festo

on-off valve
HEP-1/4-D-MIDI
Part number: 193250

Classic

Used in conjunction with service units.

Modern alternatives can be found by entering the first four characters of the type code in the search field.

Design structure  Piston slide
Type of actuation  pneumatic
Sealing principle  soft
Exhaust-air function  not throttleable
Manual override  None
Type of reset  mechanical spring
Valve function  3/2 closed, monostable
Operating pressure  0 … 16 bar
Pilot pressure  3 … 16 bar
C value  10.1 l/sbar
b value  0.46
Standard nominal flow rate  2,600 l/min
Operating medium  Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases
Design structure

Piston slide

Type of actuation

pneumatic

Sealing principle

soft

Exhaust-air function

not throttleable

Manual override

None

Type of reset

mechanical spring

Valve function

3/2 closed, monostable

Operating pressure

0 … 16 bar

Pilot pressure

3 … 16 bar

C value

10.1 l/sbar

b value

0.46

Standard nominal flow rate

2,600 l/min

Operating medium

Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases
