HEP-1/4-D-MINI

$102.70

Festo

on-off valve
HEP-1/4-D-MINI
Part number: 193244

Classic

Used in conjunction with service units.

Modern alternatives can be found by entering the first four characters of the type code in the search field.

Design structure

Piston slide

Type of actuation

pneumatic

Sealing principle

soft

Exhaust-air function

not throttleable

Manual override

None

Type of reset

mechanical spring

Valve function

3/2 closed, monostable

Operating pressure

0 … 16 bar

Pilot pressure

3 … 16 bar

C value

7.2 l/sbar

b value

0.34

Standard nominal flow rate

1,500 l/min

Operating medium

Compressed air in accordance with ISO8573-1:2010 [7:4:4]Inert gases
