LF-D-5M-MINI-A

$161.95

SKU: 192560 Category: Tag: Brand:

filter
LF-D-5M-MINI-A
Part number: 192560

Classic

Without threaded connection plates with FRB threaded pin. Degree of filtration: 5 µm, with bowl guard and automatic condensate drain.

Modern alternatives can be found by entering the first four characters of the type code in the search field.

Size Mini
Series D
Assembly position Vertical +/- 5°
Grade of filtration 5 µm
Condensate drain fully automatic
Design structure Sintered filter with centrifugal separator
Max. condensate volume 22 cm3
Bowl guard Metal bowl guard
Operating pressure 2 … 12 bar
Operating medium Compressed air to ISO 8573-1:2010 [7:9:-]Inert gases
Corrosion resistance classification CRC 2 – Moderate corrosion stress
Air purity class at output Compressed air in accordance with ISO8573-1:2010 [6:8:4]Inert gases
Medium temperature ‘-10 … 60 °C
Size

Mini

Series

D

Assembly position

Vertical +/- 5°

Grade of filtration

5 µm

Condensate drain

fully automatic

Design structure

Sintered filter with centrifugal separator

Max. condensate volume

22 cm3

Bowl guard

Metal bowl guard

Operating pressure

2 … 12 bar

Operating medium

Compressed air to ISO 8573-1:2010 [7:9:-]Inert gases

Corrosion resistance classification CRC

2 – Moderate corrosion stress

Air purity class at output

Compressed air in accordance with ISO8573-1:2010 [6:8:4]Inert gases

Medium temperature

-10 … 60 °C
